Chapter 7 Specifications
50
Duration
Range: 0, (0.5 ~999.9) s. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
Arc Detection
1 ~9 (9: most sensitive); 0: arc detection disenable
Current compensation
0.000~100.00mA, total current + compensation current ＜100mA, Auto/Manual
DCW
Rated output
6kVDC / 10mA
DC voltage output
Range: (100 ~ 6000) VDC. Resolution: 1V. Accuracy: ± (1%× setting +5V)
DC voltage measurement
Range: (0.10 ~ 6.00) kV DC. Resolution: 10V. Accuracy: ± (1%× reading +1 word)
Output ripple
<2% (6kV/1mA Resistive load)
Output adjustment
± (1%× setting +2V), Zero to Full load
Setting of current upper
limit
Range: (0.0~10000) μA. Resolution: 0.1μA/1μA. Error: ± (1%× setting +5 words)
Setting of current lower
limit
Range: (0.0~999.9) μA. Resolution: 0.1μA. Error: ± (1%× setting +5 words)
DC current measurement
Range: 0.0~3500μA/3.00~ 10.00mA. Resolution: 0.1/1μA/0.01mA. Error: ± (1%× reading +5
words)
Ramp Time
Range: 0, (0.4 ~999.9) s, 0: Off. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
Duration
Range: 0, (0.5~999.9) s, 0: infinite. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
Slow Down Time
Range: 0, (1.0~999.9) s, 0: Off. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
Arc Detection
1 ~9 (9: most sensitive); 0: arc detection disenable
Current compensation
(0 ~200.0) μA, Auto/Manual
Ramp current upper limit
ON/OFF, On current upper limit: 12mA
Charge current lower limit
(0~350.0) μA, Auto/Manual
Discharge Time
≤200ms
Maximum capacitive load
1uF＜1kV, 0.75uF＜2kV, 0.5uF＜3kV, 0.08uF＜4kV, 0.04uF＜5kV
IR
Rated output
2500VDC/50GΩ
DC voltage output
Range: (100 ~ 2500) V DC. Resolution: 1V. Accuracy: ± (1%× setting +5V)
DC voltage measurement
Range: (100 ~ 2500) V DC. Resolution: 1V. Accuracy: ± (1%× reading +5V)
Setting of resistance
upper/lower limit
Range: 1MΩ~50000MΩ. The upper limit includes infinite.
Insulation resistance
measurement
Range:1MΩ~50.00GΩ， Resolution:0.001MΩ /0.01MΩ /0.1MΩ /0.001GΩ /0.01GΩ
Error: 100V~499V:0.100MΩ~2.000GΩ, ± (5%× reading +2 words)
500V~2500V: 0.100MΩ~999.9MΩ, ± (2%× reading +2 words)
1.000GΩ~9.999GΩ: ± (5%× reading +2 words)
10.00GΩ~50.00GΩ: ± (15%× reading +2 words)
Ramp Time
Range: 0, (0.1 ~999.9) s, 0: Off. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
Delay Time
Range: 0, (0.5~999.9) s, 0: infinite. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
Slow Down Time
Range: 0.0, (1.0~999.9) s, 0: Off. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
Charge current lower limit
(0~3.500) μA, Auto/Manual
Discharge time
≤200ms
Maximum capacitive load
1uF＜1000V, 0.5uF＜2500V
GB
