Annex C Protocol
69
2
FS
Null
End the settings and save the file
3
DELI-LAST
Null
Delete the last step
4
DELI-ALL
Null
Remove all steps
5
SET-ACW
Detailed follow-up
Add a step at the end，ACW
6
SET-DCW
Detailed follow-up
Add a step at the end，DCW
7
SET-IR
Detailed follow-up
Add a step at the end，IR
8
SET-GB
Detailed follow-up
Add a step at the end，GB
9
SET-TCT
Detailed follow-up
Add a step at the end，LC
10
SET-PW
Detailed follow-up
Add a step at the end，PA
11
SET-ST
Detailed follow-up
Add a step at the end，ST
12
SET-WAIT
Detailed follow-up
Add a step at the end，WAIT
Test the relevant instructions
1
TEST
Null
start testing
2
RESET
Null
Stop the test
3
TD?
Null
Query all test data
Detailed follow-up
4
RD
RD nn?
1 to 8), - 1 = Read the current
step
Single station: Query the specified
step test data
3.3 Error return list
Index
Returns the error
string
meaning
1
UnkownCmd
Unrecognized command word
2
CanntExecute
Unable to execute this directive. Such as the non-test page in the
implementation of TEST command to return this error.
3
ExceedPara
Used for parameterized instructions, the received parameter is outside
the normal range.
3.4 Operating procedures
Test: The test flow is as follows
1) In the main interface, send ENTER-TEST to enter the test page
2) On the test page, send TEST to start the test
3) After the start of the test, send RD -1 ?, or RD nn? Real-time query the specific data for each step
Or send TD? Query all data and conclusions
4) In the test, send RESET to stop the test
5) After the test, send TEST to start the next test
Or send RETURN back to the main interface
