Chapter 7 Specifications
52
Touch/leakagecurrent
measurement (rms)
0.0μA
～
999.9μA: DC, 15Hz≤f≤100kHz: ± (1.5%× reading +10 words)
100kHz
＜
f≤1000kHz, 10.0μA
～
999.9μA: ±5%× reading
1000μA
～
7999μA: DC, 15Hz≤f≤100kHz: ± (1.5%× reading +10 words)
100kHz
＜
f≤1000kHz, 10μA
～
7999μA: ±5%× reading
8.00mA
～
12.00mA: DC: ± (1.5%× reading +10 words)
15Hz≤f
＜
1000kHz, 0.01mA~12.00mA: ±5%× reading
LC Compensation
Range: 0.000~1.000mA, Auto measurement, On or Off.
Duration
Range: 0, (1 ~999.9), 0: infinite. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word), (for test
mode AUTO (G-L, G-N): half of the duration)
DC input impedance
2kΩ ± 1% (GB12113Figure 4)
Input impedance
≤100kHz 5%; ＞100kHz 10%
Frequency response
Accuracy: same as current measurement error
PA
Alarm
Power upper/lower limit alarm;
Settings of power upper/lower
limit
Range: 0.00W~6000W. Resolution: 0.01W /0.1W /1W,
Error: ± (0.1%× setting +0.1%× range)
Active power measurement
Range: 0.10W~6.000kW. Resolution: 0.01W /0.01W /0.1W /0.001kW
Accuracy: PF＞0.5: ± (0.1%× reading +0.1%× range)
PF≤0.5: ± (0.4%× reading +0.1%× range)
Voltage measurement
Range: 5.00V~300.0V, peak factor: ≤1.6. Resolution: 0.01V /0.1V;
Accuracy: ± (0.1%× reading +0.1%× range), 45Hz≤f≤65Hz
Current measurement
Range: 0.00mA~25.00A, peak factor: ≤1.6. Resolution: 0.01mA /0.1mA /0.001A /0.01A
Accuracy: ± (0.1%× reading +0.1%× range), 45Hz≤f≤65Hz
Power factor measurement
Range: ± (0.100~1.000). Resolution: 0.001
Accuracy: ±0.01 (voltage/current amplitudes are greater than 10% of the
corresponding ranges)
Frequency measurement
Range: 45.00Hz ~65.00Hz. Resolution: 0.01Hz. Accuracy: ± (0.1%× reading )
Duration
Range: 0, (0.5~999.9) s, 0: infinite. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
ST
Settings of current upper/lower
limit
Range: (0.00~25.00) A. Resolution: 0.01A. Error: ± (0.1%× setting +0.1%× range)
Voltage measurement
Range: 5.00V~300.0V, peak factor: ≤1.6. Resolution: 0.01V /0.1V;
Accuracy: ± (0.1%× reading +0.1%× range), 45Hz≤f≤65Hz
Current measurement
Range: (0.02~25.00) A, peak factor: ≤1.6. Resolution: 0.01A
Accuracy: ± (0.1%× reading +0.1%× range), 45Hz≤f≤65Hz
Duration
Range: 0, (0.5~999.9) s, 0: infinite. Resolution: 0.1s. Accuracy: ± (0.1%× setting +2word)
97006H
Rated output
6000VA
Voltage output
Range:(0 ~300)VAC, Frequency: (45~65)Hz
7.3 Attachments
Table 7.3 Attachment
