Virtual Private LAN Services
7210 SAS-X, R6 OS Services Guide Page 233
VPLS Packet Walkthrough
This section provides an example of VPLS processing of a customer packet sent across the
network from site-A, which is connected to PE-Router-A through a 7210 SAS to site-C, which is
connected through 7210 SAS to PE-Router-C (Figure 26) in an HVPLS configuration. This
section does not discuss the processing on the PE routers, but only on 7210 SAS routers.
Figure 26: VPLS Service Architecture
7210
7210
7210
72107210
7210
PE-D
PE-A PE-C
7210
7210
OSSG486
