Virtual Private Routed Network Services
7210 SAS-X OS Services Guide Page 699
QoS Policies
When applied to a VPRN SAP, service ingress QoS policies only create the unicast queues defined
in the policyif PIM is not configured on the associated IP interface; if PIM is configured, the
multipoint queues are applied as well.
Multicast is not supported in VPRN service. Ingress queue, in addition to meters, are supported
only on 7210 SAS-X. SAP ingress meters are supported on all other platforms.
For 7210 SAS-X devices (with VPRN services), service egress QoS policies function as with
other services where the class-based queues are created as defined in the policy.
Note that both Layer 2 (but dot1p only) or Layer 3 criteria can be used in the QoS policies for
traffic classification in an VPRN.
Filter Policies
Ingress and egress IPv4 filter policies can be applied to VPRN SAPs.
