Maintenance / Reference
Optionalaccessories
 EMS-79 DTMF microphone
* No sub PTT on this model.
 EMS-78 microphone
 EJ-47U Digital voice communication unit
 EDS-30 Separation kit (5m cable + bracket + hardware)
 EDS-8 microphone conversion cable (8 pin to modular)
 ERW-7 PC connection cable
EDS-30(Optional)Installation
Be certain to turn off the radio before installation.
Fix panels with screws.
Insert the cable to the smaller connector on
the left marked SEP.
Install the panel with screws.
Make sure the position before to screw.
Insert another end of cable to the connector
on the back of the front control unit.
IMPORTANT
Never place the plug to the connector on the right of the front control unit. It is for the microphone,
and doing so may cause damage to the unit and/or the microphone.
