Chapter 2 Communications
Ɣ Each time the [M/KHz] key is pressed, ź shifts in the following manner:
źfl ashing above MHz frequency indication.
ź above MHz frequency indication.
ź fl ashing above 1 kHz frequency indication.
ź above kHz frequency indication.
• Default settings (Default band, frequency and mode for both VFO A and B)
Keypad Band (MHz) default (Mode) Keypad Band (MHz) default (Mode)
1 1.8 1.900.00 MHz (LSB) 6 14 14.100.0 MHz (USB)
2 3.5 3.600.00 MHz (LSB) 7 18 18.100.0 MHz (USB)
3 5.3 5.330.50 MHz (USB) 8 21 21.100.0 MHz (USB)
4 7 7.100.00 MHz (LSB) 9 24 24.900.0 MHz (USB)
5 10 10.100.0 MHz (USB) 0 28 28.100.0 MHz (USB)
Changes the BAND.
Changes the 1 MHz digit.
Changes the 100 kHz digit.
Changes by minimum steps.
