IMPORTANT: Please read the following pages thoroughly prior to the change of any parameters. THE
PARAMETERS CANNOT BE SET WITHOUT ENTERING THE SET MODE.
By entering the Parameter Setting mode, some of the radio’s operating parameters can be
changed to suit your preferences. The following is the Selectable Parameters’ Menu.
A List of the Setting Mode Parameters
Menu Default display Function Default Value
00 SSB-0.1 Frequency Step of the [Ÿ/ź] Keys Setting 0.1 kHz
AM-1.0 1.0 kHz
FM-2.5 2.5 kHz
01 PROT-OF Memory Overwrite Protection OFF
02 ACCS-ON Memory Frequency Access Protection ON
03 SC- 2S Timer SCAN Setting 2S
04 B-SCAN Select Scan types BAND SCAN
05 SSC-50 Search range setting for Search scan 50 kHz
06 SKIP Memory scan skip Setting SKIP
07 DIMR-32 Dimmer 32
08 BEEP-ON Beep Sound ON
09 U/L-ON Automatic USB / LSB Selection ON
10 AGC-ON Automatic AGC-S / AGC-F Selection ON
11 TXIT-ON TXIT Function Setting ON
12 EKEY-ON Electronic Keyer Setting ON
13 WPM-20 Electronic Keyer Speed Setting 20 WPM
14 PADDL-N Electronic Keyer Reverse Setting PADDLE-N
15 ST-800 Sidetone (CW Offset) Setting 800 Hz
16 BKIN-AT Break-in Delay Time for CW operation AUTO
17 RAT-3.0 Key ratio 3.0
18 T-88.5 CTCSS Tone Encoding Setting 88.5 Hz
19 SPH-OFF Speech Compressor OFF
20 PTT.L-OF PTT Key Lock OFF
21 APO-OFF APO-Auto Power OFF OFF
22 UD-RPT UP/DOWN keys function setting REPEAT
23 FUNC-MN FUNC key resume timing setting MANUAL
To Use the Parameter Setting Mode
Press [FUNC] key for more than 1 second. Alpanumeric characters will appear
1.
indicating the transceiver is in the Parameter Setting mode. Please observe the
menu number to understand which parameter you are currently dealing with.
Select a menu by pressing the [Ÿ/ź] keys, or [UP/DOWN] keys on the
2.
microphone.
Rotate the main dial to change the desired setting. In case the available parameter
3.
is 2 items, such as ON/OFF, rotate the dial clockwise or counterclockwise to select
either one.
Chapter 6 Parameter Setting Mode (Set mode)
