39
Chapter 2 Communications
2.6 General Coverage Receiver Operation
Introducution
This section explains procedures for receiving MW and SW broadcasts using the general
coverage receiver function.
Procedure
Example: Receiving a 670 kHz (0.670 MHz) MW broadcasts
Make sure that all antenna and power
1.
connections are correct.
Turn the power on. Adjust audio level.
2.
3.
Press the [M/KHz] key repeatedly until ź
fl ashing above the 1 kHz frequency
indication.
4.
Press the [Ÿ] key until 7 appears on 100 kHz
digit indication.
5.
Press the [M/KHz] key once to stop fl ashing
ź.
Press and hold [ź] key to select 70 for 10
6.
kHz and 1 kHz order. After 3 second the step
turns faster. Now the display shows 7.670.00.
7.
Press the [M/KHz] repeatedly until ź
appears above the 1 MHz frequency
indication.
To Next Page
