Set Up EtherNet/IP Communication Across Subnets 153
Set Up the Alias Topic Switcher
IMPORTANT
If you start the Alias Topic Switcher software without access to
an RSLinx activation file (for example, without a version of
RSLinx which supports OPC), this error occurs:
0x80040112
(The text for the message depends on your operating system.)
1. In the tool tray, right-click the Redundancy Switch icon and choose Open Alias Topic Switching Tool.
2. In the Redundancy Alias Topic Switching Tool window, click
.
3. Type the topic names:
a. Alias topic
b. Topic for the controller in Chassis A
c. Topic for the controller in Chassis B
4. Click .
Topic that the alias topic is currently
using
