Allen-Bradley 1756-CNB User Manual

Publication 1756-UM523F-EN-P - December 2006
Configure and Program the Controller 93
Actions
Use this table to configure a message to an SRM module.
Configuring a Message to an SRM
If you want to On this tab For this item Type or select
Initiate a switchover Configuration Message Type CIP Generic
Service Code 4e
Class name bf
Instance name 1
Attribute name Leave blank
Source INT tag with a value of 1
Num. Of Elements 2
Destination Leave blank
Communication Path 1, slot_number
where:
slot_number is the left-hand slot number of the
1757-SRM module.
Connected check box. Leave the Connected check box clear (unchecked). You can
send only unconnected messages to a 1757-SRM module.
Disqualify the secondary
controller
Configuration Message Type CIP Generic
Service Code 4d
Class name bf
Instance name 1
Attribute name Leave blank
Source INT tag with a value of 1
Num. Of Elements 2
Destination Leave blank
Communication Path 1, slot_number
where:
slot_number is the left-hand slot number of the
1757-SRM module.
Connected check box. Leave the Connected check box clear (unchecked). You can
send only unconnected messages to a 1757-SRM module.
