Publication 1756-UM523F-EN-P - December 2006
88 Configure and Program the Controller
Check Your Work
Use the Redundancy tab of the Controller Properties window to check
the code attributes. It does not show all the attributes, but it shows the
more common attributes.
Additional Resources
For more information, consult these sources.
• Appendix C
• Logix5000 Controllers General Instructions Reference Manual,
publication 1756-RM003
1. Download and run your project.
2. Open the Controller Properties window.
3. Click Redundancy.
4. Compare the Redundancy tab with your code.
In this example, the chassis ID A = 1.
