Publication 1756-UM523F-EN-P - December 2006
98 Configure and Program the Controller
10. From the Network menu, choose Single Pass Browse.
11. From the File menu, choose Save.
12. Type a name for the file that stores the network configuration,
then choose Save.
13. Select the Optimize and rewrite Schedule for all Connections
button (default) and choose OK.
Update the Schedule of an Existing Network
To update the schedule of an existing network, perform this
procedure.
1. Turn on the power to each chassis.
2. Start RSNetworx for ControlNet software.
3. From the File menu, choose Open.
4. Select the file for the network and choose Open.
5. From the Network menu, choose Online.
6. Select the Edits Enabled check box.
7. From the Network menu, choose Properties.
8. From Network Parameters, update these parameters.
9. Choose OK.
10. From the Network menu, choose Single Pass Browse.
11. From the File menu, choose Save.
12. Select the Optimize and rewrite Schedule for all Connections
button and choose OK.
In this box Specify
Max Scheduled Address Greatest node number to use scheduled communications
on the network
Max Unscheduled Address Greatest node number to use on the network
