27 Publication 1756-UM523F-EN-P - December 2006
Chapter
2
Design the System
Introduction
This chapter explains how to design a redundancy system for a
ControlLogix controller.
Topic Page
Laying Out the System 28
Placement of a Pair of Redundant Chassis 30
Placement of the I/O 31
Placement of Operator Interface Terminals 32
Additional Redundant Components 33
Checking Connection Requirements 35
Planning a ControlNet Network 35
Planning an EtherNet/IP Network 38
Additional Design Considerations 41
