Publication 1756-UM523F-EN-P - December 2006
94 Configure and Program the Controller
Synchronize the secondary
controller
Configuration Message Type CIP Generic
Service Code 4c
Class name bf
Instance name 1
Attribute name Leave blank
Source INT tag with a value of 1
Num. Of Elements 2
Destination Leave blank
Communication Path 1, slot_number
where:
slot_number is the left-hand slot number of the
1757-SRM module.
Connected check box. Leave the Connected check box clear (unchecked). You can
send only unconnected messages to a 1757-SRM module.
Set the clock of the SRM
module
Configuration Message Type CIP Generic
Service Code 10
Class name 8b
Instance name 1
Attribute name 1
Source WallClockTime[0]
where:
WallClockTime is a DINT[2] array that stores the
CurrentValue of the WALLCLOCKTIME object.
Num. Of Elements 8
Destination Leave blank
Communication Path 1, slot_number
where:
slot_number is the left-hand slot number of the
1757-SRM module.
Connected check box Leave the Connected check box clear (unchecked). You can
send only unconnected messages to a 1757-SRM module.
Configuring a Message to an SRM (Continued)
If you want to On this tab For this item Type or select
