Publication 1756-UM523F-EN-P - December 2006
170 Attributes of the Redundancy Object
Results of the compatibility
checks with the partner
controller.
CompatibilityResults INT GSV If Then
0 Undetermined
1 No compatible partner
2 Fully compatible partner
Status of the
synchronization
(qualification) process.
Qualification
InProgress
INT GSV If Then
-1 Synchronization (qualification) is not in progress.
0 Unsupported
1 - 99 For modules that can measure their completion
percentage, the percent of synchronization
(qualification) that is complete.
50 For modules that cannot measure their completion
percentage, synchronization (qualification) is in
progress.
100 Synchronization (qualification) is complete.
Keyswitch settings of the
controller and its partner
match or do not match.
KeyswitchAlarm DINT GSV If Then
0 • The keyswitches match
or
• No partner is present.
1 Keyswitches do not match
Position of the keyswitch of
the partner.
PartnerKeyswitch DINT GSV If Then the keyswitch is in
0 Unknown
1RUN
2 PROG
3REM
Status of the minor faults of
the partner (if the
ModuleRedundancyState
indicates that a partner is
present).
PartnerMinorFaults DINT GSV This
bit
Means this minor fault
1 Powerup fault
3 IO fault
4 Problem with an instruction (program)
6 Periodic task overlap (watchdog)
9 Problem with the serial port
10 Low battery
For this information Get this attribute Data
Type
GSV/SSV Description
