ControlLogix Redundancy System Overview 25
Operator Interface Terminals
Parameter Operator Interfaces Criteria Page
EtherNet/IP Network PanelView Standard terminal Same as a nonredundant system 28, 32, 38
• PanelView Plus terminal
• VersaView industrial computer running a
Windows CE operating system
• Use RSLinx Enterprise software revision
3.0 or later.
• Set aside connections for each PanelView
Plus or VersaView CE terminal:
RSView Supervisory Edition software with
RSLinx Enterprise software
• Use RSLinx Enterprise software revision
3.0 or later.
• Use IP swapping.
• Keep the HMI and both redundant chassis
on the same subnet.
• RSView Supervisory Edition software with
RSLinx 2.x software
• RSView 32 software
• Any other HMI client software that uses
RSLinx 2.x software
Limit the number of RSLinx servers that a
controller uses to 1 (ideal) to 3 (maximum).
ControlNet Network • PanelView Standard terminal
• PanelView 1000e/1400e terminal
Do terminals use unscheduled
communication?
• Yes — Use ≤ 4 terminals per controller.
• No — Use the number of terminals that
you need.
28, 32, 35
• PanelView Plus terminal
• VersaView industrial computer running a
Windows CE operating system
• Use RSLinx Enterprise software revision
3.0 or later.
• Set aside connections for each PanelView
Plus or VersaView CE terminal.
• RSView Supervisory Edition software with
RSLinx 2.x software
• RSView 32 software
• Any other HMI client software that uses
RSLinx 2.x software
Limit the number of RSLinx servers that a
controller uses to 1 (ideal) to 3 (maximum).
In this module Set aside
controller 5 connections
ENBT 5 connections
EWEB 5 connections
In this module Set aside
Controller 5 connections
CNB 5 connections
To Next Page
