A-4 Specifications
Surge Current per Point:
• peak current
• maximum surge duration
• maximum rate of repetition at 30°C (86°F)
• maximum rate of repetition at 55°C (131°F)
• 4.0A
• 10 msec
• once every second
• once every 2 seconds
• Not Applicable
• Not Applicable
• Not Applicable
• Not Applicable
Turn-On Time (maximum) 0.1 msec 6 μsec
Turn-Off Time (maximum) 1.0 msec 18 μsec
Repeatability (maximum) n/a 2 μsec
Drift (maximum) n/a 1 μsec per 5°C (9°F)
(1) Output 2 is designed to provide increased functionality over the other FET outputs. Output 2 may be used like the other FET transistor outputs, but in addition, within a
limited current range, it may be operated at a higher speed. Output 2 also provides a pulse train output (PTO) or pulse width modulation output (PWM) function.
Table A.4 BXB FET Output Specifications
Description General Operation
High Speed Operation
(1)
(Output 2 Only)
Table A.5 AC Input Filter Settings
Nominal Filter Setting (ms) ON Delay (ms) OFF Delay (ms)
Minimum Maximum Minimum Maximum
8 2 20 10 20
Table A.6 Fast DC Input Filter Settings (Inputs 0 to 3)
Nominal Filter Setting (ms) ON Delay (ms) OFF Delay (ms) Maximum Counter Frequency (Hz)
50% Duty Cycle
Minimum Maximum Minimum Maximum
0.025 0.005 0.025 0.005 0.025 20.0 kHz
0.075 0.040 0.075 0.045 0.075 6.7 kHz
0.100 0.050 0.100 0.060 0.100 5.0 kHz
0.250 0.170 0.250 0.210 0.250 2.0 kHz
0.500 0.370 0.500 0.330 0.500 1.0 kHz
1.00 0.700 1.000 0.800 1.000 0.5 kHz
2.000 1.700 2.000 1.600 2.000 250 Hz
4.000 3.400 4.000 3.600 4.000 125 Hz
8.000
(1)
6.700 8.000 7.300 8.000 63 Hz
16.000 14.000 16.000 14.000 16.000 31 Hz
(1) This is the default setting.
