Publication 1766-RM001A-EN-P - October 2008
Using High-Speed Outputs 151
PTOX Total Output Pulses To Be Generated (TOP)
The PTOX TOP (Total Output Pulses) defines the total number of pulses
to be generated for the pulse profile (accel/run/decel inclusive).
PTOX Output Pulses Produced (OPP)
The PTOX OPP (Output Pulses Produced) is generated by the PTO
sub-system and can be used in the control program to monitor how many
pulses have been generated by the PTO sub-system.
PTOX Accel/Decel Pulses Independent (ADI)
The PTOX ADI (Accel/Decel Pulses Independent) bit is used to define
whether the acceleration and deceleration intervals will be the same, or if
each will have a unique value. When this bit is set (1), separate profiles
are used. When this bit is clear (0), the PTO will operate with the
deceleration profile as a mirror of the acceleration profile.
If separate acceleration and deceleration profiles are desired, you must
choose a long integer file number and a starting element. There must be
four long elements available in the file:
Sub-Element
Description
Address Data
Format
Range Type User
Program
Access
TOP - Total Output
Pulses To Be Generated
PTOX:0.TO
P
long word
(32-bit INT)
0…2,147,483,647 control read/write
Sub-Element
Description
Address Data
Format
Range Type User Program
Access
OPP - Output
Pulses Produced
PTOX:0.OPP long word
(32-bit INT)
0…2,147,483,647 status read only
Sub-Element
Description
Address Data Format Range Type User Program
Access
ADI - Accel/Decel
Pulses Independent
PTOX:0/ADI bit 0 or 1 control read/write
Element 1: Acceleration Count
Element 2: Deceleration Count
Elements 3 and 4: Reserved
