206 Math Instructions
NEG - Negate
Instruction Type: output
Use the NEG instruction to change the sign of the Source and place the
result in the Destination.
CLR - Clear
Instruction Type: output
Use the CLR instruction to set the Destination to a value of zero.
ABS - Absolute Value
Instruction Type: output
Exeution Time for the ABS Instruction
The ABS instruction takes the absolute value of the Source and places it in
the Destination. The data range for this instruction is
-2,147,483,648…2,147,483,647 or IEEE-754 floating point value.
NEG
Negate
Source N7:0
0<
Dest N7:1
0<
NEG
Execution Time for the NEG Instruction
Controller Data Size When Rung Is:
True False
MicroLogix 1400 word 1.3570 µs 0.3548 µs
long word 1.3660 µs 0.3413 µs
CLR
Clear
Dest N7:0
0<
CLR
Execution Time for the CLR Instruction
Controller Data Size When Rung Is:
True False
MicroLogix 1400 word 2.0522 µs 0.3714 µs
long word 2.0125 µs 0.3691 µs
ABS
Absolute Value
Source N7:0
0<
Dest N7:1
0<
ABS
Controller Data Size When Rung Is:
True False
MicroLogix 1400 word 1.4410 µs 0.3750 µs
long word 1.5390 µs 0.3730 µs
