Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
Socket Interface Using CIP Generic Messaging 485
Communicate With the
Socket Object Via a
MSG Instruction
In MicroLogix controller programs, you can use a CIP Generic MSG
instruction to request socket services.
Configure the MSG with these values.
Message Parameters
CIP Generic Msg Parameter Description
Channel Select 1 (Integral)
Communication Command Select CIP Generic
Service Select Custom
