Allen-Bradley MicroLogix 1400 User Manual

629 Publication 1766-RM001A-EN-P - October 2008
Appendix E
Knowledgebase Quick Starts
The following Quick Start topics are included:
• # 17444 “Quick Start” Pulse Train Output (PTOX) on page 629
• # 17446 “Quick Start” Pulse Width Modulation (PWMX) on page 632
• # 17447 “Quick Start” High Speed Counter (HSC) on page 634
• # 17465 “Quick Start” Message (MSG) on page 638
• # 17501 “Quick Start” Selectable Timed Interrupt (STI) on page 642
• # 17503 “Quick Start” Real Time Clock (RTC) on page 644
• # 17558 “Quick Start” User Interrupt Disable (UID) on page 646
• # 18465 “Quick Start” RTC Synchronization Between Controllers on
page 647
• # 18498 “Quick Start” Data Logging (DLG) on page 650
# 17444 “Quick Start”
Pulse Train Output
(PTOX)
NOTE: The PTO and PWM functions are only available when using the
BXB or BXBA models of the MicroLogix 1400
Locate the Function Files under Controller in RSLogix 500/RSLogix Micro
v8.10.00 or later and select the PTOX tab, then select the [+] next to
PTOX:0 (See Below).
