Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
File Instructions 269
Addressing Modes and File Types are shown in the following table:
COP - Copy File
Instruction Type: output
The COP instruction copies blocks of data from one location into another.
CPW Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page 4-2.
Parameter
Data Files Function Files
CS - Comms IOS - I/O DLS - Data Log
Address
Mode
(1)
Address Level
O I S B T, C, R N F ST L MG, PD RI/RIX PLS RTC HSC PTOX, PWMX STI EII BHI MMI LCD Immediate Direct Indirect Bit Word Long Word Element
Source •• • •• • •••••••••• • ••
Destination •• • •• • •••••••
• ••
Length
•
(1) See Important note about indirect addressing.
IMPORTANT
You cannot use indirect addressing with: S, MG, PD, RTC, HSC, PTOX,
PWMX, STI, EII, BHI, MMI, CS, IOS, and DLS files.
COP
Copy File
Source #N7:0
Dest #N7:1
Length 1
COP
Execution Time for the COP Instruction
Controller When Rung Is:
True False
MicroLogix 1400 3.6020 µs 0.1853 µs
COP Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page 92.
Parameter
Data Files Function Files
CS - Comms IOS - I/O DLS - Data Log
Address
Mode
(1)
Address Level
O I S B T, C, R N F ST L MG, PD RI/RIX PLS RTC HSC PTOX, PWMX STI EII BHI MMI LCD Immediate Direct Indirect Bit Word Long Word Element
Source •• •••••• • • ••
Destination •• •••••• •
• ••
Length
•
(1) See Important note about indirect addressing.
