Publication 1766-RM001A-EN-P - October 2008

Function Files 89

Input/Output Status File

The input/output status (IOS) file is a read-only file in the controller that

contains information on the status of the embedded and local expansion

I/O. The data file is structured as:

Input/Output Status File

Word Description

0 Embedded Module Error Code – Always zero

1…4 Expansion Module Error Code – The word number corresponds to the module’s slot number. Refer to the I/O module’s

documentation for specific information. (MicroLogix 1400)
