Publication 1766-RM001A-EN-P - October 2008
Using High-Speed Outputs 161
PWMX Output (OUT)
The PWMX OUT (Output) variable defines the physical output that the
PWM instruction controls. This variable is set within the function file
folder when the control program is written and cannot be set by the user
program. The outputs are defined as O0:0/2, O0:0/3 or O0:0/4 as listed
below:
• O0:0.0/2: PWM modulates output 2 of the embedded outputs.
• O0:0.0/3: PWM modulates output 3 of the embedded outputs.
• O0:0.0/4: PWM modulates output 4 of the embedded outputs.
PWMX Decelerating Status (DS)
The PWMX DS (Decel) bit is controlled by the PWM sub-system. It can be
used by an input instruction on any rung within the control program. The
DS bit operates as follows:
• Set (1) - Whenever a PWM output is within the deceleration phase
of the output profile.
• Cleared (0) - Whenever a PWM output is not within the deceleration
phase of the output profile.
PWMX Run Status (RS)
The PWMX RS (Run Status) bit is controlled by the PWM sub-system. It
can be used by an input instruction on any rung within the control
program.
Element
Description
Address Data
Format
Range Type User Program Access
OUT - PWM Output PWMX:0.OU
T
word (INT) 2…4 status read only
Element Description Address Data Format Range Type User Program
Access
DS - Decelerating Status PWM:0/DS bit 0 or 1 status read only
Element Description Address Data Format Range Type User Program
Access
RS - PWM Run Status PWMX:0/RS bit 0 or 1 status read only
