Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
Compare Instructions 195
• If the Test parameter is a word or long word address, the Low Limit
and High Limit parameters can be either a constant, a word, or a
long word address.
When mixed-sized parameters are used, all parameters are put into the
format of the largest parameter. For instance, if a word and a long word
are used, the word is converted to a long word.
The data ranges are:
• -32,768…32,767 (word)
• -2,147,483,648…2,147,483,647 (long word)
Addressing Modes and File Types can be used as shown in the following
table:
LIM Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page 92.
Parameter
Data Files
Function Files
(1)
CS - Comms IOS - I/O DLS - Data Log
Address
Mode
(2)
Address Level
O I S B T, C, R N F ST L MG, PD RI/RIX PLS RTC HSC PTOX, PWMX STI EII BHI MMI LCD Immediate Direct Indirect Bit Word Long Word Element
Low Limit •••••• ••• •••••••••••• • •••
Test •••••• ••• •••••••••••
• • •••
High Limit •••••• ••• •••••••••••
• • •••
(1) PTOX and PWMX files are only for use with MicroLogix 1400 BXB or BXBA unit.
(2) See Important note about indirect addressing.
IMPORTANT
You cannot use indirect addressing with: S, MG, PD, RTC, HSC, PTOX,
PWMX, STI, EII, BHI, MMI, CS, IOS, and DLS files.
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley MicroLogix 1400 Specifications

General

Processor	32-bit
Expansion Modules	Up to 7 expansion I/O modules
Power Supply	24V DC or 120/240V AC
Programming Software	RSLogix 500
Communication Ports	Ethernet, RS-232/RS-485 combo port
Controller Type	Programmable Logic Controller (PLC)
Series	MicroLogix
Digital Outputs	12
Analog Inputs	6 (embedded)
Analog Outputs	2 (embedded)
High-Speed Counter	6 high-speed counters
Pulse Output	2 (embedded)
Ethernet Port	Yes
