Allen-Bradley MicroLogix 1400 User Manual

267 Publication 1766-RM001A-EN-P - October 2008
Chapter 15
File Instructions
The file instructions perform operations on file data.
Instruction Used To: Page
CPW - Copy Word Copy words of data from one location to
another
268
COP - Copy File Copy a range of data from one file
location to another
269
FLL - Fill File Load a file with a program constant or a
value from an element address
271
BSL - Bit Shift Left Load and unload data into a bit array one
bit at a time
272
BSR - Bit Shift Right 274
FFL - First In, First Out (FIFO) Load Load words into a file and unload them in
the same order (first in, first out)
277
FFU - First In, First Out (FIFO)
Unload
279
LFL - Last In, First Out (LIFO) Load Load words into a file and unload them in
reverse order (last in, first out)
282
LFU - Last In, First Out (LIFO)
Unload
284
SWP - Swap Swap low byte with high byte in a
specified number of words
286
