The IIM instruction allows you to selectively update input data without
waiting for the automatic input scan. This instruction uses the following
operands:
• Slot - This operand defines the location where data is obtained for
updating the input file. The location specifies the slot number and
the word where data is to be obtained. For example, if slot = I:0,
input data from slot 0 starting at word 0 is masked and placed in
input data file I:0 starting at word 0 for the specified length. If slot =
I:0.1, word 1 of slot 0 is used, and so on.
• Mask - The mask is a hex constant or register address containing the
mask value to be applied to the slot. If a given bit position in the
mask is a “1”, the corresponding bit data from slot is passed to the
input data file. A “0” prohibits corresponding bit data in slot from
being passed to the input data file. The mask value can range from
0…0xFFFF.
• Length - This is the number of masked words to transfer to the
input data file.
Addressing Modes and File Types can be used as shown below:
IMPORTANT
Slot 0 is the only valid slot number that can be used with this
instruction. IIM cannot be used with expansion I/O.
Bit 1514131211109876543210
Real Input Input Word
Mask 0000000011111111
Input Data
File
Data is Not Updated Updated to Match Input Word
IIM Instruction Valid Addressing Modes and File Types
For definitions of the terms used in this table see Using the Instruction Descriptions on page 92.
Parameter
Data Files Function Files
CS - Comms
IOS - I/O
DLS - Data Log
Address
Mode
Address Level
O
I
S
B
T, C, R
N
F
ST
L
MG, PD
RI/RIX
PLS
RTC
HSC
PTOX, PWMX
STI
EII
BHI
MMI
LCD
Immediate
Direct
Indirect
Bit
Word
Long Word
Element
Slot • • • •
Mask •• •••
• • ••
Length
•
