Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
402 Communications Instructions
The Control Bits, Sub-Element 16, of the MSG File Element are defined
below:
The Status Bits, Sub-Element 17, of the MSG File Element are defined
below.
Message File Target Location Information
Target Device = CIP Generic
Sub-
Element
Name Description Paramete
r
Size User
Program
Access
12 Target Class Y Word read only
13 Target Instance Y Word read/write
14 CIP Send Data Count Y Word read/write
15 Internal Physical Address of
CIP Send Data Table
Address operand
Y Word read only
Message File Sub-Element 16 - Control Bits
Bit Address Description Parameter Size User
Program
Access
15 MG11:0.0/EN Enable
1=MSG enabled
0=MSG not enabled
N bit read/write
9…1
4
Reserved N bit read/write
8 MG11:0.0/TO Time Out
1=MSG time out by user
0=no user MSG time out
N bit read/write
1…7 Reserved N bit read/write
0 MG11:0.0/BK Break Connection
For Channel 1,
1=MSG Connection closed by
user
0=MSG Connection not closed
by user
N bit read/write
