Publication 1766-RM001A-EN-P - October 2008

44 Controller Memory and File Types

Viewing Controller Memory Usage

1. Highlight and open Controller Properties.

2. The amount of Memory Used and Memory Left will appear in the

Controller Properties window once the program has been verified.
