Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
560 System Status File
STI Enabled
This address is duplicated at STI:0/TIE. SeeUsing the Selectable Timed
Interrupt (STI) Function File on page 318 for more information.
STI Executing
This address is duplicated at STI:0/UIX. SeeUsing the Selectable Timed
Interrupt (STI) Function File on page 318 for more information.
Memory Module Program Compare
When this bit is set (1) in the controller, its user program and the memory
module user program must match for the controller to enter an executing
mode.
If the user program does not match the memory module program, or if
the memory module is not present, the controller faults with error code
0017H on any attempt to enter an executing mode.
See also:LPC - Load Program Compare on page 61.
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:2/1 binary 0 or 1 control read/write
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:2/2 binary 0 or 1 control read only
Address Data Format Range Type User Program Access
S:2/9 binary 0 or 1 control read only
