587 Publication 1766-RM001A-EN-P - October 2008
Appendix
D
Protocol Configuration
Use the information in this appendix for configuring communication
protocols. The following protocols are supported from any RS-232
communication channel:
• DH-485
• DF1 Full-Duplex
• DF1 Half-Duplex
• DF1 Radio Modem
• Modbus RTU
• ASCII
• DNP3 Slave
This appendix is organized into the following sections:
• DH-485 Communication Protocol on page 588
• DF1 Full-Duplex Protocol on page 592
• DF1 Half-Duplex Protocol on page 593
• DF1 Radio Modem Protocol on page 604
• Modbus RTU Protocol on page 611
• ASCII Driver on page 623
• Ethernet Driver on page 625
See your controller’s User Manual, 1766-UM001
for information about
required network devices and accessories.
See Appendix F in your controller’s User Manual, 1766-UM001
for more
information about configuring serial channel(s) for DNP3 Slave.
