Allen-Bradley MicroLogix 1400 User Manual

Publication 1766-RM001A-EN-P - October 2008
Function Files 83
5 12 Advertise 100 MB Full Duplex Flag
This bit indicates advertisement status if Auto negotiate enabled:
•0: 100 MB Full Duplex was not advertised during auto negotiation
•1: 100 MB Full Duplex was advertised during auto negotiation
13 Advertise 100 MB Half Duplex Flag
This bit indicates advertisement status if Auto negotiate enabled:
•0: 100 MB Half Duplex was not advertised during auto negotiation
•1: 100 MB Half Duplex was advertised during auto negotiation
14 Advertise 10 MB Full Duplex Flag
This bit indicates advertisement status if Auto negotiate enabled:
•0: 10 MB Full Duplex was not advertised during auto negotiation
•1: 10 MB Full Duplex was advertised during auto negotiation
15 Configuration End Flag
This bit is set (1) when the Ethernet boot-up sequence is completed, including IP address, gateway address, subnet
mask and etc.
6…8 - Ethernet Hardware Address (6-byte string)
A unique Ethernet hardware address assigned to this processor.
9…10 - IP Address (in network byte order)
Internet address that is specified for this processor.
11…12 - Subnet Mask (in network byte order)
Subnet mask that is specified for this processor
13…14 - Gateway Address (in network byte order)
Gateway address that is specified for this processor
15…16 - Broadcast Address (in network byte order)
NOT SUPPORTED AT THIS TIME. The Broadcast Address is used in sending multicast messages. A Broadcast Address
of all zeros indicates that no broadcast address was configured. In this case, the network code chooses a valid
broadcast address when needed for that current subnet.
17…18 - Primary Name Server(in network byte order)
Primary Name Server that is specified for this processor.
19…20 - Secondary Name Server(in network byte order)
Secondary Name Server that is specified for this processor.
21…52 - Default Domain Name
Default domain name that is specified for this processor.
General Channel Status Block
Word Bit Description
