APPENDIX A: TECHNICAL SPECIFICATIONS
HF-2500A HIGH FREQUENCY WELD CONTROL
A-2 990-371
Performance Capabilities
Number of Weld Schedules ...................................................................................................................100
Programmable Weld Periods:
Squeeze ................................................................................................................................ 0 – 999 ms
Upslope 1 ................................................................................................................................ 0 – 99 ms
Weld 1 .................................................................................................................................. 0 – 99 ms
Downslope 1 ........................................................................................................................... 0 – 99 ms
Cool .................................................................................................................................. 0 – 99 ms
Upslope 2 ............................................................................................................................... 0 – 99 ms
Weld 2 .................................................................................................................................. 0 – 99 ms
Downslope 2 ........................................................................................................................... 0 – 99 ms
Hold ................................................................................................................................ 0 – 999 ms
Weld Head System Compatibility
Force Fired, Foot Actuated
Force Fired, Single Valve Air Actuated
Non Force-Fired, Single Valve Air or Cam Actuated
Force Fired, EZ Air Kit
Plug-and-Play 24VDC EZ-AIR weld head
SL-300A/320A Electronic Weldheads
Weld Energy Limits Monitoring
Weld Pre-Check Mode: Inhibit second weld pulse when first test pulse exceeds programmed limits.
Measurement Parameters: Current, voltage and power.
Measurement Selection: Peak or average.
Measurement Range and Accuracy:
Parameter Range Accuracy
Current 0.1 - 2.4 kA ± (2% of setting +2 A)
Voltage 0.2 - 9.999 V ± (2% of setting +0.02 V)
Power 0.05 - 9.999 kW ± (5% of setting +10 W)
Limit Ranges: Same as the measurement ranges
Alarms: Display alert and four programmable AC/DC relay contact outputs.
