Primera BAG0175.3
1. Fill the seed hopper with at least 1/3 of the
hopper volume (in the case of fine seeds
correspondingly less).
2. Remove the calibration trough from the
bracket
3. Calibrate the seed: Rotate the calibration
trough and push back onto the bracket (
94).
4. Repeat the calibration procedure according
to the software operating manual until the
desired spread rate is achieved.
5. After the calibration test: Close the injector
sluice flap and fasten the calibration trough
in parking position.
After the calibration test, close the rotary shutters of all the injector
sluices!
For maize, the calibration test should be related to an area of 1/10 ha.
