Amazone DMC 6000-2C - Coupling the Hydraulic Hose Lines

Structure and function
44
Primera BAG0175.3
07.18
Implement without on-board hydraulic system:
Folding using
tractor control
units
Function Hose identification
red
Blower
Double acting
Blower fan leakage oil
Pressure-free return flow
WARNING
Risk of infection from hydraulic fluid escaping at high pressure.
When coupling/uncoupling the hydraulic hose line, ensure that the
hydraulic system is not under pressure on the tractor or machine side.
If you are injured by hydraulic fluid, contact a doctor immediately.
Maximum permissible pressure in oil return: 10 bar
Therefore do not connect the oil return to the tractor control unit, but
to a pressure-free oil return flow with a large plug coupling.
WARNING
For the oil return, use only DN16 lines and select short return
paths.
Pressurise the hydraulic system only when the free return has
been correctly coupled.
Install the coupling union (supplied) on the pressure-free oil return
flow.
5.2.1 Coupling the hydraulic hose lines
WARNING
Risk of contusions, cutting, catching, drawing in and knocks
from faulty hydraulic functions when the hydraulic hose lines
are connected incorrectly.
When coupling the hydraulic hose lines, observe the coloured mark-
ings on the hydraulic plugs.
