Coupling and uncoupling the machine
02
Primera BAG0175.3
7.1 Coupling the tensioned crosspiece
Coupling the tensioned crosspiece
1. Fasten the ball sleeves on the lower link pins of the implement.
2. Secure the lower link pins with linch pins to ensure that they do
not accidentally become loose.
3. Direct people out of the danger area between the tractor and
implement before you approach the implement with the tractor.
4. Drive the tractor in reverse towards the implement so that the
lower link hooks of the tractor pick up the lower ball sleeves of
the lower pivot point of the implement.
→ The lower link hooks lock automatically.
5. Secure the tractor against unintentional start-up and uninten-
tional rolling.
6. Perform a visual check to ensure proper locking of the lower link
hooks.
7. Couple the supply lines with the tractor.
8. Raise the jack and secure with a linch pin.
9. Disengage parking brake.
10. Remove wheel chocks.
Uncoupling the tensioned crosspiece
1. Secure the tractor against unintentional rolling away.
2. Lower the jack and secure with a linch pin.
3. Apply the parking brake.
4. Apply wheel chocks.
5. Disconnect the supply lines.
6. Release the lower links.
7. Unlock and uncouple the lower link hooks from the tractor cab.
