Amazone DMC 6000-2C User Manual

Cleaning, maintenance and repairs
Primera
BAG0175.3 07.18
151
12.9 On-board hydraulics
• Change the oil of the on-board hydraulics.
Required oil volume: 32 – 35 litres.) Pay at-
tention to the mark on the oil dipstick (A /
B).
• Replace the oil filter set.
1. Place a suitable container under the drain
valve (Fig. 138/1) (capacity of at least 35 li-
tres).
2. Release and remove the oil dipstick
(1).
3. Undo the drain plug.
→ Old oil flows out of the oil tank.
4. Check the seal on the drain plug and re-
place if necessary.
5. Retighten the drain plug.
6. Loosen the 3 screws on the oil filter (1),
replace the oil filter insert.
7. Fill the oil via the opening for the oil dipstick.
8. Screw the oil dipstick and seal back in and
check the oil level.
Fig.
127
Fig.
128
Fig.
129
CAUTION
After use, the oil can become very
hot. Danger of burning.
Only use HLP22 hydraulic fluid.
