Amazone DMC 6000-2C - Chisels

Structure and function
Primera
BAG0175.3 07.18
71
5.14 Chisels
Fig. 42
The chisel coulters (Fig. 55/1) are arranged in 3 or 4 rows that are
offset to each other. The row spacing is 18.75 cm or 25 cm.
The double rollers installed behind the chisel coulter regulate the
depth of the chisel coulters (Fig. 55/2).
The double rollers are also responsible for closing the seeding furrow.
The placement depth is adjusted using the crank (Fig. 55/3).
Fig. 43
(1) Standard bit for direct seeding: the seed is laid in a row.
(2) Band bit for mulch seeding: the seed is laid in a broader band.
