8.3 Setting the fill level sensor
The fill level sensor is accessible via
the maintenance flap on the hopper.
You can only adjust the height of the fill level
sensor when the seed hopper is empty:
1. Apply the parking brake, switch the tractor
engine off and remove the ignition key.
Fig. 88
2. Loosen the wing nut (Fig. 22/2).
3. Adjust the height of the fill level sensor (
Fig.
22/1) to the required seed volume.
4. Tighten the wing nut (Fig. 22/2).
Fig.
89
The fill level sensor should only be
installed as shown in Figure (Fig. 22)!
The fill level sensor may not, as shown
in Figure (Fig. 23), rest on the hopper
housing!
Increase the residual seed volume that
triggers the alarm
• the coarser the seeds
• the higher the spread rate,
• the greater the working width.
Fig. 90
