Amazone DMC 6000-2C - Hopper with Swivelable Cover

Structure and function
Primera
BAG0175.3 07.18
83
5.24 Hopper with swivelable cover
(1) Hopper with 4200 litre total capacity.
ο Content of seed hopper: 3150 l
ο Content of fertiliser hopper (optional):
1050 l
(2) Swivel cover with activation lever to open
and close the swivel cover.
Hopper extension (optional)
There is also a hopper extension with a capacity
of 800 l / 1600 l.
Fig.
63
Sieve for protection against foreign bodies:
Folding sieve in the seed hopper with sieve lock.
The sieve can be unlocked and folded using the
unlocking tool.
(1) Handle with sieve locking mechanism
(2) Unlocking tool
Fig.
64
Open the guard screen:
1. Insert the unlocking tool into the handle.
2. Hold the handle and turn the unlocking tool
to the handle.
→ Guard screen locking mechanism unlocked.
3. Raise the guard screen until it catches onto
the edge of the tank.
4. Secure the unlocking tool in the parking
position.
Fig.
65
