Amazone DMC 6000-2C - Filling Auger (Optional)

Structure and function
Primera
BAG0175.3 07.18
87
5.29 Filling auger (optional)
As an option, the machine can be fitted with a
filling auger.
Fill the filling auger with seed or fertiliser from the
transport vehicle via a chute and supply it into
the hopper of the DMC.
Fig.
71
Folded-in condition of the filling auger for
transport and use.
Fig.
72
The collection bucket is used to collect
any residual amounts.
After folding into the transport position,
empty the collection bucket.
Fig.
73
Fig. 82/…
(1) Turn on the filling auger
(2) Swivel the discharge
(3) Folding in and out
Fig.
74
