Amazone DMC 6000-2C - Placing the Machine in the Transport Position

Transportation
Primera
BAG0175.3 07.18
119
9.1 Placing the machine in the transport position
CAUTION
Before retracting the machine, fold the track marker into the
transport position.
Switch the machine from the working position to
the transport position (Fig. 112):
1. Actuate green tractor control unit.
→ Fold the track marker into the transport
position.
2. Secure the machine.
3. Cover the exact harrow with road safety
bars.
4. Move the ball valve to position A
Fig.
102
Fig.
103
Fig.
104
5. Activate yellow tractor control unit.
→ The booms are folded in.
6. Both stop taps: close the harrow folding.
