Structure and function
46
Primera BAG0175.3
07.18
WARNING
To avoid damage, only engage the universal joint shaft slowly at
low tractor engine speed.
Oil tank
(1) Suction hose to the pump
(2) Oil filter with contamination level indicator
Fill the suction line of the pump with oil be-
fore initial operation!
Fig.
12
(3) Oil tank
(4) Drain plug
Fig.
13
Oil cooler
There is an oil cooler on the fan to cool the i
m-
plement's own oil supply to the fan.
Fig.
14
