Putting into operation
166
UF 01 DB 238. 07.04
Calculation formula and reply to question 2:
Available spray mixture [l] – residual amount [l]
required rate of water [l/ha]
=
area to be sprayed [ha]
1000 [l] (Nominal tank volume) – 20 [l] (residual amount)
500 [l/ha] required rate of water
=
1.96 [ha]
6.4.1.2 Filling table for finishing off remaining field areas
Important!
For determining the required refilling amount for the last spray
agent tank filling use the "Filling table for residual areas". De-
duct the surplus amount in the spray line from the calculated
refilling quantity. For this see chapter "Spray lines", page 133.
Hint!
The indicated refilling quantities are valid for an application rate
of 100 l/ha. For all other spray rates the refilling quantity has to
be increased by a multiple.
Refilling quantities [l] for sprayer booms in working widths of
distance
[m]
10 m 12 m 15 m 16 m 18 m 20 m 21 m 24 m
10 1 1 2 2 2 2 2 2
20 2 2 3 3 4 4 4 5
30 3 4 5 5 5 6 6 7
40 4 5 6 6 7 8 8 10
50 5 6 8 8 9 10 11 12
60 6 7 9 10 11 12 13 14
70 7 8 11 11 13 14 15 17
80 8 10 12 13 14 16 17 19
90 9 11 14 14 16 18 19 22
100 10 12 15 16 18 20 21 24
200 20 24 30 32 36 40 42 48
300 30 36 45 48 54 60 63 72
400 40 48 60 64 72 80 84 96
500 50 60 75 80 90 100 105 120
Fig. 180
Example:
Remaining left over distance: 100 m
Spray rate: 100 l/ha
Sprayer booms: Q-plus-boom
Working width: 15 m
Number of boom part section feed controls: 5
Residual amount spray line: 5.2 l
1. Determine the refilling quantity with the aid of the filling table. For
this example, the refilling quantity is 15 l.
2. Deduct the residual amount in the spray line from the calculated
refilling quantity.
Necessary refilling quantity: 15 l – 5.2 l = 9.8 l
