Assembly and function
44
UF 01 DB 238. 07.04
4.3 Pump equipment
At random available pumps with a capacity of
210 l/min. and 250 l/min.
All components which come into contact with
spray agents have been made from injection
moulded plastic coated aluminium or entirely
from plastic. As far as we are aware these
pumps are suitable for the application of all
commercially available crop protective agents
and liquid fertiliser.
Important!
Never exceed the maximum pump
speed of 550 R.P.M.!
Fig. 14
Technical data pump equipment
Pump equipment 210 l/min 250 l/min
Type of pump
BP 235 BP 280
at 2 bar 208 250
Pump capacity at 540 R.P.M. [l/min]
at 20 bar 202 240
Power requirement [kW] 8.4 9.8
Kind of pump 6-cylinder
piston diaphragm pump
Pulsing damping Oil-damping
Residual amount [l] 6 6
Total weight
Pump equipment [kg] 34 40
