Product description
40
UF 01 DB 238. 07.04
3.4 Technical data
The following tables show the technical data for the individual compo-
nents. By combination of the individual components many model
variations result. For determining the total implement weight, there-
fore, please add the individual weights of the components. All indi-
cated weights and lengths are therefore to be understood as "addi-
tions".
3.4.1 Basic implement
Type 8)
Spray cocktail tank
Actual 1720 1980
Nominal
[l]
1500 1800
Basic weight 433 454
Allowable total weight
[kg]
3200 3600
Allowable pressure in system [bar] 10
Filling height
• from the ground 2060 2260
• from the ladder 1280 1480
Length ** 950
Width 2280
Height
[mm]
2280 2480
Three point linkage cat. II
Technical residual amount Suction
device (Reversing tap Spraying op-
eration / Flushing in Position "Flush-
ing")
• on level ground 9
• When operating across slopes**
• 20% in driving direction to
the left hand 11
• 20% in driving direction to
the right hand 12
• Dropping line**
• 20% Up hill 10
• 20% down hill
[l]
10
Central control Electric, coupling of part section valves
Spray pressure-adjustment electric
Spray pressure-setting range [bar] 0.8 – 10
Spray pressure gauge digital spray pressure gauge
Pressure filter 50 (80) Mesh
Agitation can be set in 6 steps
Spray rate control Speed related via job computer
* measured from lower link arms-connection
** Percent figure relates to the angle in the mentioned line
