Structure and function
ZA
-X BAG0235.4 01.23
39
• Before closing the guard screen,
push down the lock (Fig. 18).
• The guard screen locks automati-
cally once closed.
Fig.
18
5.3 Guard tube (protective device)
Serves as a bumper for the prevention of acci-
dents when the spreading discs are in operation.
Fig. 19/1:
• for ZA-X 903 / 1403
Fig.
19
Fig. 20/1:
• for ZA-X 603 / ZA-XW
Fig.
20
