Coupling and uncoupling the machine
ZA-X BAG0235.4
7.2 Uncoupling the machine
WARNING
Danger of injury due to the filled implement tipping.
Couple and uncouple the implement only when it is empty.
When uncoupling the machine, there must always be enough space
in front of the machine, so that you can align the tractor with the ma-
chine if necessary.
1. Park the empty machine on a horizontal space with a hard sur-
face.
2. Uncouple the machine from the tractor.
2.1 Secure the machine against unintentionally rolling away.
See page 70.
2.2 Relieve the load from the upper link.
2.3 Unlock and uncouple the upper link hooks from the tractor
seat.
2.4 Relieve the load from the lower link.
2.5 Unlock and uncouple the lower link hooks from the tractor
seat.
2.6 Draw the tractor approximately 10 in / 25 cm forwards.
→ The space created between the tractor and the machine al-
lows better access for decoupling the PTO shaft and the
supply lines.
2.7 Secure the tractor and machine against unintentional start-
ing and unintentional rolling away.
2.8 Decouple the PTO shaft.
2.9 Place the PTO shaft in the holder provided.
2.10 Uncouple the supply lines.
2.11 Fasten the supply lines in the corresponding parking sock-
ets.
