6.2 Adjusting the length of the PTO shaft to the tractor
WARNING
Dangers exist from damaged and/or destroyed, flying parts if the
PTO shaft is upended or pulls apart while the machine coupled
to the tractor is being raised/lowered because the length of the
PTO shaft has not been adjusted properly.
Have the length of the PTO shaft in all operational positions checked
by a specialised workshop and, if necessary, adjusted before cou-
pling the PTO shaft to your tractor for the first time.
In this way, you prevent upending of the PTO shaft or insufficient
profile overlap.
This adjustment of the PTO shaft applies only for the current tractor
type. You may need to readjust the PTO shaft if you couple the ma-
chine to another tractor. When adjusting the PTO shaft, it is mandato-
ry to observe the operating manual from the PTO shaft manufacturer.
WARNING
Danger of being caught and drawn in if the PTO shaft is installed
incorrectly or if unauthorised design changes are made.
Only a specialist workshop may make design changes to the PTO
shaft. When doing so, read and follow the operating manual from the
manufacturer.
Adjusting the length of the PTO shaft is permitted with consideration
of the minimum profile overlap.
Design changes to the PTO shaft that are not described in the operat-
ing manual from the PTO shaft manufacturer are not permitted.
WARNING
Danger of being crushed between the rear of the tractor and the
machine when raising and lowering the machine to determine
the shortest and longest operating position of the PTO shaft.
Only actuate the operator controls for the tractor's three-point hydrau-
lic system
• from the intended workstation.
•
if you are outside of the danger area between the tractor and the
machine.
